• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Number of teeth	30
Product Type	Gearbelt Pulley
Width (mm)	19.05 mm
Bore Range	1/2 to 2
Bore Type	Bushed Bore
Material	Steel
Flange (in)	3.80 in
Outside Diameter (mm)	90.1954 mm
Belt Section	L
Pitch Diameter (in)	3.581 in
Width (in)	0.75 in
Inside Diameter (in)	2.0625 in
Outside Diameter (in)	3.551 in
Face Width	1
Hub Diameter (in)	3.13 in
Overall Length (in)	1.825 in
With Flanges	With Flanges
Pulley Construction	Solid
Number of Hubs	1
Length Through Bore	1.33
Hub Projection	0.95

General Specifications

UPC	662289349715
Weight	1.49 LB
Packaged Length	4.30 IN
Packaged Width	4.30 IN
Packaged Height	1.30 IN
HTC	8483.50.9080
Country of Origin	United States of America
