• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Width (mm)	38.1 mm
Product Type	Gearbelt Pulley
Number of teeth	30
Bore Range	1/2 to 1 3/4
Bore Type	Bushed Bore
Material	Ductile Iron
Pitch Diameter (in)	4.775 in
Outside Diameter (in)	4.721 in
Width (in)	1.5 in
Outside Diameter (mm)	119.9134 mm
Flange (in)	5.0000 in
Belt Section	H
Face Width	1.75
Hub Diameter (in)	3 in
Pulley Construction	Solid
Hub Projection	0.88
Overall Length (in)	2.219 in
Number of Hubs	1
Length Through Bore	1.938
With Flanges	With Flanges

General Specifications

UPC	662289184019
Weight	6.69 LB
Packaged Length	5.40 IN
Packaged Width	5.30 IN
Packaged Height	3.40 IN
HTC	8483.50.9080
Country of Origin	United States of America
