• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Product Type	Gearbelt Pulley
Bore Range	3/4 to 2 3/8
Width (mm)	25.4 mm
Number of teeth	30
Model Name	GBPulley_Master2
Bore Type	Rough Bore
Material	Steel
Belt Section	H
Outside Diameter (mm)	119.9134 mm
Width (in)	1 in
Outside Diameter (in)	4.721 in
Pitch Diameter (in)	4.775 in
Flange (in)	5.0000 in
Face Width	1.3125
Hub Projection	1.0625
Overall Length (in)	2.375 in
Number of Hubs	1
Bore Diameter (in)	0.75 in
Length Through Bore	2.375
Hub Diameter (in)	3.625 in
Pulley Construction	Solid
With Flanges	With Flanges

General Specifications

UPC	662289142538
Weight	8.41 LB
Packaged Length	5.40 IN
Packaged Width	5.30 IN
Packaged Height	3.20 IN
HTC	8483.50.9080
Country of Origin	United States of America
