• Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets.
• Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor.
• Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement.
• Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper and QD Bushing styles, as well as, finished and minimum plain bore.

Technical Specifications

Bore Range	1/2 to 2
Product Type	Gearbelt Pulley
Model Name	GBPulley_Master6
Width (mm)	25.4 mm
Number of teeth	30
Material	Steel
Bore Type	Bushed Bore
Width (in)	1 in
Pitch Diameter (in)	4.775 in
Outside Diameter (mm)	119.9134 mm
Inside Diameter (in)	3.75 in
Flange (in)	5.0000 in
Belt Section	H
Outside Diameter (in)	4.721 in
Face Width	1.312
Hub Projection	0.95
Pulley Construction	Solid
Overall Length (in)	2.26225 in
Number of Hubs	1
Length Through Bore	1.83
With Flanges	With Flanges
Hub Diameter (in)	3.13 in

General Specifications

UPC	662289349579
Weight	4.49 LB
Packaged Length	5.40 IN
Packaged Width	5.50 IN
Packaged Height	2.10 IN
HTC	8483.50.9080
Country of Origin	United States of America
