• Exclusive Taper Bushing: Single TorqTaper Bushing installs from either side of the unit for easy on - easy off mounting, with stabilizer ring.
• Standard Bearings: Commercially available Tapered Roller Bearings provide maximum overhung load capacity.

Technical Specifications

Shaft keyseat	3/4 x 3/8 x 6 3/4
Compatible Bore Size [Max] (in)	2.9375 in
Material	Ductile Iron
Product Type	TorqTaper Plus Bushing Kit
Model Name	307TBP
Length Through Bore (in)	6.75 in
Bore Size (in)	2.9375 in
Total Length (in)	6.75 in
Outside Diameter (in)	6.44 in
Bore Type	Inch
Bushing Type	Tapered Bushing Kit
Includes	Bushing, Key, Capscrews, stablizer ring

General Specifications

UPC	662460502236
Weight	15.47 LB
Packaged Length	7.50 IN
Packaged Width	7.40 IN
Packaged Height	7.90 IN
