• Exclusive Taper Bushing: Single TorqTaper Bushing installs from either side of the unit for easy on - easy off mounting, with stabilizer ring.
• Standard Bearings: Commercially available Tapered Roller Bearings provide maximum overhung load capacity.

Technical Specifications

Model Name	307TBP
Compatible Bore Size [Max] (in)	2.375 in
Product Type	TorqTaper Plus Bushing Kit
Outside Diameter (in)	6.44 in
Total Length (in)	6.75 in
Shaft keyseat	5/8 x 5/16 x 6 3/4
Length Through Bore (in)	6.75 in
Material	Ductile Iron
Bore Size (in)	2.375 in
Bore Type	Inch
Bushing Type	Tapered Bushing
Includes	Bushing, Key, Capscrews, stablizer ring

General Specifications

UPC	662460502182
Weight	18.20 LB
Packaged Length	7.38 IN
Packaged Width	7.38 IN
Packaged Height	7.50 IN
