• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Overall Length (in)	3.078125 in
Pitch Diameter (C)	9.2
Bushing Used	Q1
Model Name	2TC-L_Sheave_Master
Outside Diameter (in)	9.2 in
Pulley Material	Cast Iron
Material	Cast Iron
Datum Diameter (C)	8.8
Number of Grooves	2
Belt Section	C
Bore (Min) (in)	0.75 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Bushing Bore Range	2.6875 - 2.6875
Keyway Size	.500

General Specifications

UPC	662289253210
Weight	17.98 LB
Packaged Length	9.06 IN
Packaged Width	9.06 IN
Packaged Height	3.75 IN
HTC	8483.50.9040
Country of Origin	Mexico
