• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Bushing Used	Q1
Material	Cast Iron
Model Name	2TC-L_Sheave_Master
Number of Grooves	2
Overall Length (in)	3.078125 in
Pulley Material	Cast Iron
Outside Diameter (in)	12.4 in
Pitch Diameter (C)	12.4
Datum Diameter (C)	12
Belt Section	C
Bore (Min) (in)	0.75 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Overall Width (in)	3.03125
Keyway Size	.500
Bushing Bore Range	2.6875 - 2.6875
Pulley Construction	Spoked
Face Width (in)	2.25

General Specifications

UPC	662289133703
Weight	25.39 LB
Packaged Length	13.40 IN
Packaged Width	13.10 IN
Packaged Height	2.60 IN
