• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Model Name	2TC-L_Sheave_Master
Outside Diameter (in)	10.6 in
Number of Grooves	2
Pitch Diameter (C)	10.6
Pulley Material	Cast Iron
Overall Length (in)	3.078125 in
Material	Cast Iron
Bushing Used	Q1
Datum Diameter (C)	10.2
Belt Section	C
Bore (Min) (in)	0.75 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Bushing Bore Range	2.6875 - 2.6875
Overall Width (in)	3.03125
Keyway Size	.500
Face Width (in)	2.25
Pulley Construction	Spoked

General Specifications

UPC	662289310692
Weight	20.87 LB
Packaged Length	11.80 IN
Packaged Width	11.90 IN
Packaged Height	2.50 IN
