• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Overall Length (in)	2.828125 in
Datum Diameter (A)	8.6
Outside Diameter (in)	9.35 in
Pitch Diameter (A)	8.8
Datum Diameter (B)	9
Pitch Diameter (B)	9.3
Pulley Material	Cast Iron
Bushing Used	Q1
Model Name	2TB-L_Sheave_Master
Number of Grooves	2
Material	Cast Iron
Bore (Min) (in)	0.75 in
Belt Section	A, B
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Face Width (in)	1.75
Keyway Size	.500
Pulley Construction	Spoked
Bushing Bore Range	2.6875 - 2.6875
Overall Width (in)	2.78125

General Specifications

UPC	662289202102
Weight	15.92 LB
Packaged Length	10.00 IN
Packaged Width	10.00 IN
Packaged Height	1.90 IN
