• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pulley Material	Cast Iron
Outside Diameter (in)	8.88 in
Model Name	2TB-L_Sheave_Master
Pitch Diameter (A)	8.4
Number of Grooves	2
Pitch Diameter (B)	8.9
Datum Diameter (B)	8.6
Overall Length (in)	2.828125 in
Datum Diameter (A)	8.2
Material	Cast Iron
Bushing Used	Q1
Belt Section	A, B
Product Type	Multiple Sheaves
Bore (Min) (in)	0.75 in
Bore Type	Split Taper Bushed
Pulley Construction	Webbed
Face Width (in)	1.75
Bushing Bore Range	2.6875 - 2.6875
Overall Width (in)	2.78125
Keyway Size	.500

General Specifications

UPC	662289302062
Weight	16.45 LB
Packaged Length	9.06 IN
Packaged Width	9.06 IN
Packaged Height	1.75 IN
