• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (A)	6.6
Overall Length (in)	2.140625 in
Datum Diameter (A)	6.4
Material	Cast Iron
Bushing Used	P1
Datum Diameter (B)	6.8
Pulley Material	Cast Iron
Model Name	2TB-L_Sheave_Master
Outside Diameter (in)	7.15 in
Pitch Diameter (B)	7.1
Number of Grooves	2
Product Type	Multiple Sheaves
Bore (Min) (in)	0.5 in
Belt Section	A, B
Bore Type	Split Taper Bushed
Number of Hubs	1
Overall Width (in)	2.14
Pulley Construction	Web
Bushing Bore Range	.500 - 1.750
Keyway Size	0.375
Face Width (in)	1.75

General Specifications

UPC	662289301836
Weight	9.71 LB
Packaged Length	7.60 IN
Packaged Width	7.60 IN
Packaged Height	1.90 IN
