• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Bushing Used	P1
Material	Cast Iron
Model Name	2TB-L_Sheave_Master
Number of Grooves	2
Pulley Material	Cast Iron
Outside Diameter (in)	6.95 in
Overall Length (in)	2.140625 in
Pitch Diameter (B)	6.9
Pitch Diameter (A)	6.4
Datum Diameter (B)	6.6
Datum Diameter (A)	6.2
Belt Section	A, B
Bore (Min) (in)	0.5 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Keyway Size	.375
Face Width (in)	1.75
Bushing Bore Range	0.500 - 1.750
Overall Width (in)	2.1875
Pulley Construction	Webbed

General Specifications

UPC	662289151875
Weight	8.85 LB
Packaged Length	7.00 IN
Packaged Width	7.30 IN
Packaged Height	1.90 IN
