• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	2
Material	Cast Iron
Model Name	2TB-M_Sheave_Master
Overall Length (in)	2.140625 in
Outside Diameter (in)	5.55 in
Pulley Material	Cast Iron
Bushing Used	P1
Pitch Diameter (A)	5
Pitch Diameter (B)	5.5
Datum Diameter (B)	5.2
Datum Diameter (A)	4.8
Bore (Min) (in)	0.5 in
Belt Section	A, B
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Pulley Construction	Plain
Bushing Bore Range	0.500 - 1.750
Keyway Size	.375
Overall Width (in)	2.1875
Face Width (in)	1.75

General Specifications

UPC	662289211487
Weight	6.57 LB
Packaged Length	7.10 IN
Packaged Width	7.30 IN
Packaged Height	1.90 IN
