• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Overall Length (in)	2.140625 in
Datum Diameter (A)	4.6
Pitch Diameter (B)	5.3
Material	Cast Iron
Bushing Used	P1
Number of Grooves	2
Outside Diameter (in)	5.35 in
Datum Diameter (B)	5
Model Name	2TB-M_Sheave_Master
Pitch Diameter (A)	4.8
Pulley Material	Cast Iron
Product Type	Multiple Sheaves
Bore (Min) (in)	0.5 in
Belt Section	A, B
Bore Type	Split Taper Bushed
Pulley Construction	Plain
Keyway Size	.375
Overall Width (in)	2.1875
Bushing Bore Range	0.500 - 1.750
Face Width (in)	1.75

General Specifications

UPC	662289281442
Weight	5.98 LB
Packaged Length	6.20 IN
Packaged Width	6.10 IN
Packaged Height	2.50 IN
