• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	2
Outside Diameter (in)	16.35 in
Model Name	2TB-L_Sheave_Master
Bushing Used	Q1
Pulley Material	Cast Iron
Material	Cast Iron
Overall Length (in)	2.828125 in
Pitch Diameter (A)	15.8
Pitch Diameter (B)	16.3
Datum Diameter (A)	15.6
Datum Diameter (B)	16
Product Type	Multiple Sheaves
Belt Section	A, B
Bore (Min) (in)	0.75 in
Number of Hubs	1
Bore Type	Split Taper Bushed
Pulley Construction	Spoke
Bushing Bore Range	2.6875 - 2.6875
Face Width (in)	1.75
Keyway Size	0.5
Overall Width (in)	2.79

General Specifications

UPC	662289222421
Weight	30.24 LB
Packaged Length	17.10 IN
Packaged Width	17.00 IN
Packaged Height	2.00 IN
