• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Overall Length (in)	3.171875 in
Bushing Used	R1
Outside Diameter (in)	15 in
Material	Cast Iron
Belt Type	Classic or 358
Number of Hubs	1
Number of Flanges	3
Pulley Material	Cast Iron
Pitch Diameter (5V)	14.9
Number of Grooves	2
Product Type	Multiple Sheaves
Belt Section	5V
Bore (Min) (in)	1.125 in
Bore Type	Split Taper Bushed
Face Width (in)	1.6875
Keyway Size	.750
Bushing Bore Range	1.125 - 3.750

General Specifications

UPC	662289312108
Weight	29.87 LB
Packaged Length	16.40 IN
Packaged Width	16.30 IN
Packaged Height	2.50 IN
