• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Outside Diameter (in)	9.75 in
Pitch Diameter (5V)	9.65
Overall Length (in)	2.828125 in
Material	Cast Iron
Number of Grooves	2
Bushing Used	Q1
Pulley Material	Cast Iron
Belt Section	5V
Bore (Min) (in)	0.75 in
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Overall Width (in)	2.78125
Keyway Size	.500
Bushing Bore Range	2.6875 - 2.6875
Face Width (in)	1.6875
Pulley Construction	Spoked

General Specifications

UPC	662289250783
Weight	15.89 LB
Packaged Length	10.00 IN
Packaged Width	10.10 IN
Packaged Height	2.00 IN
