• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (5V)	8.9
Overall Length (in)	2.828125 in
Bushing Used	Q1
Outside Diameter (in)	9 in
Material	Cast Iron
Pulley Material	Cast Iron
Number of Grooves	2
Product Type	Multiple Sheaves
Bore (Min) (in)	0.75 in
Belt Section	5V
Bore Type	Split Taper Bushed
Pulley Construction	Webbed
Keyway Size	.500
Overall Width (in)	2.78125
Bushing Bore Range	2.6875 - 2.6875
Face Width (in)	1.6875

General Specifications

UPC	662289312030
Weight	17.35 LB
Packaged Length	9.06 IN
Packaged Width	9.06 IN
Packaged Height	1.75 IN
