• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Overall Length (in)	2.828125 in
Number of Grooves	2
Pulley Material	Cast Iron
Outside Diameter (in)	7.1 in
Bushing Used	Q1
Pitch Diameter (5V)	7
Material	Cast Iron
Bore (Min) (in)	0.75 in
Product Type	Multiple Sheaves
Belt Section	5V
Bore Type	Split Taper Bushed
Keyway Size	.500
Pulley Construction	Plain
Bushing Bore Range	2.6875 - 2.6875
Face Width (in)	1.6875
Overall Width (in)	2.78125

General Specifications

UPC	662289100446
Weight	10.63 LB
Packaged Length	8.10 IN
Packaged Width	8.10 IN
Packaged Height	1.90 IN
