• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pulley Material	Cast Iron
Outside Diameter (in)	11.8 in
Number of Grooves	2
Pitch Diameter (5V)	11.7
Bushing Used	Q1
Overall Length (in)	2.828125 in
Material	Cast Iron
Bore (Min) (in)	0.75 in
Product Type	Multiple Sheaves
Belt Section	5V
Bore Type	Split Taper Bushed
Keyway Size	.500
Bushing Bore Range	2.6875 - 2.6875
Pulley Construction	Spoked
Overall Width (in)	2.78125
Face Width (in)	1.6875

General Specifications

UPC	662289170920
Weight	21.80 LB
Packaged Length	12.75 IN
Packaged Width	12.75 IN
Packaged Height	1.75 IN
