• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Overall Length (in)	2.828125 in
Material	Cast Iron
Outside Diameter (in)	6.9 in
Bushing Used	Q1
Pulley Material	Cast Iron
Number of Grooves	2
Pitch Diameter (3V)	6.85
Belt Section	3V
Product Type	Multiple Sheaves
Bore (Min) (in)	0.75 in
Bore Type	Split Taper Bushed
Bushing Bore Range	2.6875 - 2.6875
Pulley Construction	Spoked
Overall Width (in)	2.78125
Keyway Size	.500
Face Width (in)	1.0938

General Specifications

UPC	662289311910
Weight	10.33 LB
Packaged Length	7.20 IN
Packaged Width	7.30 IN
Packaged Height	2.00 IN
