• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Outside Diameter (in)	14 in
Pitch Diameter (3V)	13.94
Pulley Material	Cast Iron
Bushing Used	Q1
Overall Length (in)	2.828125 in
Material	Cast Iron
Number of Grooves	2
Bore (Min) (in)	0.75 in
Product Type	Multiple Sheaves
Belt Section	3V
Bore Type	Split Taper Bushed
Keyway Size	.500
Overall Width (in)	2.78125
Face Width (in)	1.0938
Bushing Bore Range	2.6875 - 2.6875
Pulley Construction	Spoked

General Specifications

UPC	662289311941
Weight	23.30 LB
Packaged Length	14.00 IN
Packaged Width	14.00 IN
Packaged Height	1.75 IN
