• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	2
Bushing Used	P1
Pulley Material	Cast Iron
Pitch Diameter (5V)	4.3
Material	Cast Iron
Overall Length (in)	2.515625 in
Outside Diameter (in)	4.4 in
Bore (Min) (in)	0.5 in
Belt Section	5V
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Keyway Size	.375
Bushing Bore Range	0.500 - 1.750
Face Width (in)	1.6875
Overall Width (in)	2.1875
Pulley Construction	Plain

General Specifications

UPC	662289446162
Weight	3.62 LB
Packaged Length	5.40 IN
Packaged Width	5.00 IN
Packaged Height	2.00 IN
