• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Overall Length (in)	2.140625 in
Pitch Diameter (3V)	5.25
Pulley Material	Cast Iron
Bushing Used	P1
Material	Cast Iron
Outside Diameter (in)	5.3 in
Number of Grooves	2
Product Type	Multiple Sheaves
Belt Section	3V
Bore (Min) (in)	0.5 in
Bore Type	Split Taper Bushed
Face Width (in)	1.0938
Bushing Bore Range	0.500 - 1.750
Pulley Construction	Plain
Keyway Size	.375
Overall Width (in)	2.1875

General Specifications

UPC	662289311842
Weight	5.58 LB
Packaged Length	5.56 IN
Packaged Width	5.56 IN
Packaged Height	1.13 IN
