• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Bushing Used	P1
Overall Length (in)	2.140625 in
Material	Cast Iron
Pitch Diameter (3V)	4.7
Outside Diameter (in)	4.75 in
Number of Grooves	2
Pulley Material	Cast Iron
Product Type	Multiple Sheaves
Belt Section	3V
Bore (Min) (in)	0.5 in
Bore Type	Split Taper Bushed
Bushing Bore Range	0.500 - 1.750
Overall Width (in)	2.1875
Keyway Size	.375
Pulley Construction	Plain
Face Width (in)	1.0938

General Specifications

UPC	662289189540
Weight	4.05 LB
Packaged Length	5.56 IN
Packaged Width	5.56 IN
Packaged Height	1.13 IN
HTC	8483.50.9040
Country of Origin	Mexico
