• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Bushing Used	P1
Pitch Diameter (3V)	4.45
Material	Cast Iron
Pulley Material	Cast Iron
Overall Length (in)	2.140625 in
Number of Grooves	2
Outside Diameter (in)	4.5 in
Product Type	Multiple Sheaves
Bore (Min) (in)	0.5 in
Belt Section	3V
Bore Type	Split Taper Bushed
Face Width (in)	1.0938
Overall Width (in)	2.1875
Keyway Size	.375
Bushing Bore Range	0.500 - 1.750
Pulley Construction	Plain

General Specifications

UPC	662289119455
Weight	3.67 LB
Packaged Length	4.70 IN
Packaged Width	4.80 IN
Packaged Height	1.50 IN
