• Large Selection - MVP companion sheaves are offered in A/B, C, 5Vand 8V belt sections and from 3-10 grooves giving Browning the largest selection of MVP Companion Sheaves in the industry.
• Statically Balanced - All MVP companion sheaves are statically balanced to assure smooth, vibration free performance.
• VP sheaves consist of a male with a threaded barrel, and a female with a threaded bore.
• The male section with threaded barrel has flat surfaces at 180 degree increments that allow a flat surface for the setscrew to mate with.
• When discs are moved toward each other, the belt rides higher in the groove and the pitch diameter of the sheave is larger which increases the driven speed.
• When discs are moved away from each other, the belt rides lower and the pitch diameter is smaller decreasing the driven speed.

Technical Specifications

Face Width (Min) (in)	2.78125 in
Face Width (Max) (in)	3.375 in
Outside Diameter (in)	11.06 in
Material	Cast Iron
Product Type	MVP Sheaves
Outside Length (in)	4.625 in
Number of Grooves	2
Type of Bore	Bushed
Ring	6.5
Pitch Diameter Range (C)	11.1 - 8.9
Bore (Min) (in)	1 in
Belt Section	C
Bore (Max) (in)	2.625 in
Bushing Used	Q2
Bore Type	Split Taper Bushed
Keyway Size	.500
Bushing Bore Range	1.000 - 2.625

General Specifications

UPC	662289145041
Weight	51.15 LB
Packaged Length	11.06 IN
Packaged Width	11.06 IN
Packaged Height	4.63 IN
HTC	8483.50.9040
Country of Origin	United States of America
