• Wrapped construction - Browning offers a full line of wrapped FHP Belts which provides smooth quiet operation. Wrapped FHP Belts are more tolerant to slipping and misalignment than Raw Edge Belts.
• The best features of notched and wrapped belts. Designed for small sheave applications - Browning FHP Belts are formulated for maximum flexibility for use in small diameter sheaves.

Technical Specifications

Pitch Length	31.6
Belt Section	2L
Construction Type	Wrapped
Reinforcing cord material	Polyester
Standards met	ARPM IP-23
Belt Series	FHP Belts
Color	Black
Section Size	2L
Material	Rubber
Cross Section	0.28131
Operating Temperature [Max] ºC	60 °C
Product Type	FHP Belt
Outside Length/Diameter (in)	32 in
Operating Temperature [Max] ºF	140 °F
Overall Width (in)	0.28125 in
Width (in)	0.25 in
Resistance Features	Oil & Chemical per ARPM IP-3-2, Static Dissipating per ARPM IP-3-3
Operating Temperature Range	-32 to +140 °F
Part Height	.156

General Specifications

UPC	662289164837
Weight	0.07 LB
Packaged Length	3.65 IN
Packaged Width	13.85 IN
Packaged Height	0.45 IN
HTC	4010.32.3000
Country of Origin	Mexico
