• Ideal for Pulsing loads - All Browning Banded Belts provide the belt solution for pulsing/shock loads and the demands of the aggregate industry. The Banding material aids in preventing material from getting between the sheave and belts.
• Eliminates the possibility of belt turnover on narrow and long centers - Banded Belts assure all belts within the drive run in uniformity to the sheaves without any possibility of belt turnover, even when centers are very long.

Technical Specifications

Type	Gripband Notched Belts
Pitch Length	61.8
Number of Ribs	2
Belt Section	GBBX
Cross Section	21/32 x 7/16
Material	Neoprene
Operating Temperature [Max] ºF	140 °F
Product Type	Banded Belt
Operating Temperature [Max] ºC	60 °C
Height	0.4375
Reinforcing cord material	Synthetic Fiber
Band Type	Belt with Ends Joined
Width (in)	1.3125 in
Outside Length/Diameter (in)	60 in
Construction Type	Notched
Section Size	GBBX

General Specifications

UPC	662289015085
Weight	1.18 LB
Packaged Length	19.40 IN
Packaged Width	20.45 IN
Packaged Height	2.55 IN
HTC	4010.31.3000
Country of Origin	United States of America
