• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Outside Diameter (in)	6.4 in
Material	Cast Iron
Bushing Used	Q1
Overall Length (in)	2.828125 in
Pitch Diameter (C)	6.4
Datum Diameter (C)	6
Number of Grooves	2
Pulley Material	Cast Iron
Product Type	Multiple Sheaves
Belt Section	C
Bore (Min) (in)	0.75 in
Bore Type	Split Taper Bushed
Overall Width (in)	2.78125
Face Width (in)	2.25
Keyway Size	.500
Bushing Bore Range	2.6875 - 2.6875
Pulley Construction	Webbed

General Specifications

UPC	662289311118
Weight	9.47 LB
Packaged Length	6.70 IN
Packaged Width	6.60 IN
Packaged Height	2.40 IN
HTC	8483.50.9040
Country of Origin	Mexico
