• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Bushing Used	SF
Datum Diameter (C)	20
Pulley Material	Cast Iron
Outside Diameter (in)	20.4 in
Number of Grooves	2
Pitch Diameter (C)	20.4
Model Name	2C_LG_Sheavemaster
Material	Cast Iron
Bore (Min) (in)	0.5 in
Product Type	Multiple Sheaves
Belt Section	C
Bore Type	QD Bushed
Bushing Bore Range	0.500 - 2.938

General Specifications

UPC	662289322817
Weight	48.00 LB
Packaged Length	20.40 IN
Packaged Width	20.40 IN
Packaged Height	2.25 IN
