• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pitch Diameter (C)	14.4
Bushing Used	R1
Datum Diameter (C)	14
Outside Diameter (in)	14.4 in
Material	Cast Iron
Number of Grooves	2
Pulley Material	Cast Iron
Overall Length (in)	3.296875 in
Bore (Min) (in)	1.125 in
Belt Section	C
Product Type	Multiple Sheaves
Bore Type	Split Taper Bushed
Pulley Construction	Spoked
Keyway Size	.750
Face Width (in)	2.25
Overall Width (in)	3.28125
Bushing Bore Range	1.125 - 3.750

General Specifications

UPC	662289136636
Weight	32.35 LB
Packaged Length	15.75 IN
Packaged Width	15.75 IN
Packaged Height	2.25 IN
