• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Datum Diameter (C)	13
Bushing Used	SF
Model Name	2C_LG_Sheavemaster
Number of Grooves	2
Pulley Material	Cast Iron
Material	Cast Iron
Pitch Diameter (C)	13.4
Outside Diameter (in)	13.4 in
Product Type	Multiple Sheaves
Belt Section	C
Bore (Min) (in)	0.5 in
Bore Type	QD Bushed
Overall Width (in)	2.25
Bushing Bore Range	0.500 - 2.938
Pulley Construction	Spoked
Face Width (in)	2.25

General Specifications

UPC	662289322800
Weight	27.28 LB
Packaged Length	14.80 IN
Packaged Width	14.30 IN
Packaged Height	2.70 IN
