• Largest Selection of H Bushed sheaves of any other manufacturer - Browning offers bushed sheaves in both A and B Combination (A/B) configuration. 1 and 2 Grooves are available to meet any fractional horsepower requirement.
• Sheaves are Statically Balanced - All sheaves are statically balanced to assure smooth, vibration free performance.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.
• Combination Groove - All Browning BK H Sheaves permit the running of A, 4L, B and 5L Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.

Technical Specifications

Number of Grooves	2
Pitch Diameter (A)	15.2
Type of Bore	Bushed
Datum Diameter (B)	15.4
Pitch Diameter (B)	15.7
Datum Diameter (A)	15
Model Name	2BKH_Sheave_Master
Material	Cast Iron
Bore (Min) (in)	0.375 in
Belt Section	4L or A, 5L or B
Outside Length (in)	1.75 in
Product Type	FHP - Bushed
Outside Diameter (in)	15.75 in
Bore Type	Split Taper Bushed
Bushing Bore Range	0.375 - 1.500
Face Width (in)	1.75
Pulley Construction	Plain
Overall Width (in)	1.75

General Specifications

UPC	662289272839
Weight	20.19 LB
Packaged Length	16.63 IN
Packaged Width	16.63 IN
Packaged Height	1.75 IN
HTC	8483.50.9040
Country of Origin	Mexico
