• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	2
Model Name	2AB_LG_Sheavemaster
Pulley Material	Cast Iron
Bushing Used	SK
Outside Diameter (in)	9.75 in
Material	Cast Iron
Pitch Diameter (A)	9.2
Pitch Diameter (B)	9.7
Datum Diameter (A)	9
Datum Diameter (B)	9.4
Product Type	Multiple Sheaves
Belt Section	A, B
Bore (Min) (in)	0.5 in
Bore Type	QD Bushed
Overall Width (in)	1.75
Pulley Construction	Spoked
Face Width (in)	1.75
Bushing Bore Range	0.500 - 2.625

General Specifications

UPC	662289332939
Weight	13.90 LB
Packaged Length	10.00 IN
Packaged Width	9.90 IN
Packaged Height	1.90 IN
