• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	2
Model Name	2AB_LG_Sheavemaster
Pitch Diameter (B)	7.7
Pitch Diameter (A)	7.2
Pulley Material	Cast Iron
Outside Diameter (in)	7.68 in
Datum Diameter (B)	7.4
Bushing Used	SK
Material	Cast Iron
Datum Diameter (A)	7
Belt Section	A, B
Product Type	Multiple Sheaves
Bore (Min) (in)	0.5 in
Bore Type	QD Bushed
Face Width (in)	1.75
Bushing Bore Range	0.500 - 2.625
Pulley Construction	Spoked
Overall Width (in)	1.75

General Specifications

UPC	662289402922
Weight	10.72 LB
Packaged Length	8.10 IN
Packaged Width	8.10 IN
Packaged Height	2.00 IN
