• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Model Name	2AB_LG_Sheavemaster
Bushing Used	SK
Material	Cast Iron
Number of Grooves	2
Datum Diameter (B)	7
Pitch Diameter (A)	6.8
Datum Diameter (A)	6.6
Pulley Material	Cast Iron
Outside Diameter (in)	7.35 in
Pitch Diameter (B)	7.3
Product Type	Multiple Sheaves
Belt Section	A, B
Bore (Min) (in)	0.5 in
Bore Type	QD Bushed
Bushing Bore Range	0.500 - 2.625
Overall Width (in)	1.75
Face Width (in)	1.75
Pulley Construction	Plain

General Specifications

UPC	662289372904
Weight	10.77 LB
Packaged Length	8.10 IN
Packaged Width	8.00 IN
Packaged Height	2.00 IN
