• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pulley Material	Cast Iron
Bushing Used	SDS
Datum Diameter (A)	6.2
Outside Diameter (in)	6.95 in
Pitch Diameter (B)	6.9
Number of Grooves	2
Datum Diameter (B)	6.6
Model Name	2AB_LG_Sheavemaster
Pitch Diameter (A)	6.4
Material	Cast Iron
Bore (Min) (in)	0.5 in
Belt Section	A, B
Product Type	Multiple Sheaves
Bore Type	QD Bushed
Face Width (in)	1.75
Overall Width (in)	1.75
Bushing Bore Range	0.500 - 2.000
Pulley Construction	Webbed
Length Through Bore (in)	1.3125 in

General Specifications

UPC	662289412945
Weight	7.44 LB
Packaged Length	7.00 IN
Packaged Width	7.20 IN
Packaged Height	2.10 IN
