• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pulley Material	Cast Iron
Number of Grooves	2
Datum Diameter (A)	5.6
Outside Diameter (in)	6.35 in
Overall Length (in)	2.828125 in
Material	Cast Iron
Datum Diameter (B)	6
Pitch Diameter (B)	6.3
Bushing Used	Q1
Pitch Diameter (A)	5.8
Belt Section	A, B
Product Type	Multiple Sheaves
Bore (Min) (in)	0.75 in
Bore Type	Split Taper Bushed
Keyway Size	.500
Overall Width (in)	2.78125
Face Width (in)	1.75
Pulley Construction	Plain
Bushing Bore Range	2.6875 - 2.6875

General Specifications

UPC	662289204427
Weight	8.87 LB
Packaged Length	6.80 IN
Packaged Width	6.80 IN
Packaged Height	2.40 IN
