• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Material	Cast Iron
Model Name	2B5V-SheaveMaster
Outside Diameter (in)	8.28 in
Pitch Diameter (B)	8.3
Datum Diameter (B)	8
Datum Diameter (A)	7.6
Pitch Diameter (A)	7.8
Number of Grooves	2
Pitch Diameter (5V)	8.1
Bushing Used	B
Pulley Material	Cast Iron
Overall Length (in)	2.546875 in
Product Type	Multiple Sheaves
Bore (Min) (in)	0.5 in
Belt Section	A, B, 5V
Bore Type	Split Taper Bushed
Keyway Size	0.500
Face Width (in)	1.7188
Pulley Construction	Spoked
Bushing Bore Range	0.500 - 2.4375
Overall Width (in)	2.484375

General Specifications

UPC	662289034710
Weight	11.08 LB
Packaged Length	9.30 IN
Packaged Width	9.30 IN
Packaged Height	1.90 IN
