• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Overall Length (in)	2.546875 in
Datum Diameter (B)	5
Outside Diameter (in)	5.28 in
Material	Cast Iron
Pitch Diameter (A)	4.8
Pitch Diameter (5V)	5.1
Pitch Diameter (B)	5.3
Model Name	2B5V-SheaveMaster
Datum Diameter (A)	4.6
Pulley Material	Cast Iron
Number of Grooves	2
Bushing Used	B
Product Type	Multiple Sheaves
Belt Section	A, B, 5V
Bore (Min) (in)	0.5 in
Number of Hubs	1
Bore Type	Split Taper Bushed
Face Width (in)	1.72
Overall Width (in)	2.44
Pulley Construction	Solid
Bushing Bore Range	0.500 - 2.4375
Keyway Size	0.500

General Specifications

UPC	662289034482
Weight	4.46 LB
Packaged Length	7.20 IN
Packaged Width	7.30 IN
Packaged Height	2.00 IN
