• Combination Groove - All Browning B5V Sheaves permit the running of A, 4L, B, 5L and 5V Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Broad horsepower coverage - The B5V is available in 1 through 6 grooves allowing it to cover from 5 to 125 horsepower drives
• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• New Casting design - The B5V castings were developed using CAD and Finite Elements Analysis to determine where to add and eliminate material.

Technical Specifications

Overall Length (in)	2.546875 in
Datum Diameter (A)	10.6
Outside Diameter (in)	11.28 in
Number of Grooves	2
Datum Diameter (B)	11
Pitch Diameter (B)	11.3
Pitch Diameter (A)	10.8
Bushing Used	B
Model Name	2B5V-SheaveMaster
Material	Cast Iron
Pulley Material	Cast Iron
Pitch Diameter (5V)	11.1
Product Type	Multiple Sheaves
Bore (Min) (in)	0.5 in
Belt Section	A, B, 5V
Number of Hubs	1
Bore Type	Split Taper Bushed
Keyway Size	0.500
Pulley Construction	Spoke
Bushing Bore Range	0.500 - 2.4375
Overall Width (in)	2.53
Face Width (in)	1.72

General Specifications

UPC	662289034253
Weight	15.96 LB
Packaged Length	11.50 IN
Packaged Width	11.40 IN
Packaged Height	1.90 IN
