• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Bushing Used	Q1
Overall Length (in)	2.828125 in
Outside Diameter (in)	6.15 in
Material	Cast Iron
Pitch Diameter (B)	6.1
Pulley Material	Cast Iron
Pitch Diameter (A)	5.6
Datum Diameter (A)	5.4
Number of Grooves	2
Datum Diameter (B)	5.8
Bore (Min) (in)	0.75 in
Product Type	Multiple Sheaves
Belt Section	A, B
Bore Type	Split Taper Bushed
Overall Width (in)	2.78125
Bushing Bore Range	2.6875 - 2.6875
Keyway Size	.500
Pulley Construction	Plain
Face Width (in)	1.75

General Specifications

UPC	662289264339
Weight	8.09 LB
Packaged Length	6.90 IN
Packaged Width	6.80 IN
Packaged Height	2.10 IN
