• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pulley Material	Cast Iron
Number of Grooves	2
Bushing Used	SDS
Model Name	2AB_LG_Sheavemaster
Outside Diameter (in)	5.95 in
Material	Cast Iron
Pitch Diameter (A)	5.4
Pitch Diameter (B)	5.9
Datum Diameter (B)	5.6
Datum Diameter (A)	5.2
Belt Section	A, B
Product Type	Multiple Sheaves
Bore (Min) (in)	0.5 in
Bore Type	QD Bushed
Bushing Bore Range	0.500 - 2.000
Face Width (in)	1.75
Overall Width (in)	1.75
Pulley Construction	Webbed
Length Through Bore (in)	1.3125 in

General Specifications

UPC	662289352883
Weight	6.16 LB
Packaged Length	7.00 IN
Packaged Width	7.30 IN
Packaged Height	1.80 IN
