• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Outside Diameter (in)	5.95 in
Bushing Used	Q1
Pulley Material	Cast Iron
Datum Diameter (B)	5.6
Pitch Diameter (B)	5.9
Overall Length (in)	2.828125 in
Material	Cast Iron
Datum Diameter (A)	5.2
Number of Grooves	2
Pitch Diameter (A)	5.4
Bore (Min) (in)	0.75 in
Product Type	Multiple Sheaves
Belt Section	A, B
Bore Type	Split Taper Bushed
Pulley Construction	Plain
Face Width (in)	1.75
Overall Width (in)	2.78125
Bushing Bore Range	2.6875 - 2.6875
Keyway Size	.500

General Specifications

UPC	662289104376
Weight	7.38 LB
Packaged Length	7.00 IN
Packaged Width	7.30 IN
Packaged Height	1.80 IN
