• Incorporates Browning Split Taper Bushing - The only bushing system that provides a true Key-to-Key drive to both the shaft and the hub.
• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Overall Length (in)	2.828125 in
Pulley Material	Cast Iron
Outside Diameter (in)	5.75 in
Material	Cast Iron
Number of Grooves	2
Bushing Used	Q1
Pitch Diameter (B)	5.7
Pitch Diameter (A)	5.2
Datum Diameter (A)	5
Datum Diameter (B)	5.4
Product Type	Multiple Sheaves
Bore (Min) (in)	0.75 in
Belt Section	A, B
Bore Type	Split Taper Bushed
Face Width (in)	1.75
Pulley Construction	Plain
Keyway Size	.500
Overall Width (in)	2.78125
Bushing Bore Range	2.6875 - 2.6875

General Specifications

UPC	662289234233
Weight	6.64 LB
Packaged Length	7.20 IN
Packaged Width	7.40 IN
Packaged Height	1.80 IN
