• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Pulley Material	Cast Iron
Material	Cast Iron
Model Name	2AB_LG_Sheavemaster
Bushing Used	SF
Outside Diameter (in)	30.35 in
Number of Grooves	2
Pitch Diameter (B)	30.3
Pitch Diameter (A)	29.8
Datum Diameter (A)	29.6
Datum Diameter (B)	30
Bore (Min) (in)	0.5 in
Product Type	Multiple Sheaves
Belt Section	A, B
Bore Type	QD Bushed
Face Width (in)	1.75
Bushing Bore Range	0.500 - 2.938

General Specifications

UPC	662289322640
Weight	51.00 LB
Packaged Length	30.35 IN
Packaged Width	30.35 IN
Packaged Height	1.75 IN
HTC	8483.50.9040
Country of Origin	China
