• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Number of Grooves	2
Datum Diameter (B)	18.4
Bushing Used	SK
Pitch Diameter (B)	18.7
Material	Cast Iron
Datum Diameter (A)	18
Pulley Material	Cast Iron
Model Name	2AB_LG_Sheavemaster
Outside Diameter (in)	18.75 in
Pitch Diameter (A)	18.2
Belt Section	A, B
Bore (Min) (in)	0.5 in
Product Type	Multiple Sheaves
Bore Type	QD Bushed
Face Width (in)	1.75
Bushing Bore Range	0.500 - 2.625
Pulley Construction	Spoked
Overall Width (in)	1.75

General Specifications

UPC	662289346837
Weight	29.95 LB
Packaged Length	18.75 IN
Packaged Width	18.75 IN
Packaged Height	1.75 IN
