• Combination Groove - All Browning B Sheaves permit the running of A and B Belts to be run in them, thus providing a variety of different pitch diameters and horsepowers.
• Close Grain Cast iron - Close grain cast iron allows Browning to machine our sheaves to the closest tolerances possible.

Technical Specifications

Model Name	2AB_LG_Sheavemaster
Number of Grooves	2
Number of Hubs	1
Datum Diameter (A)	15
Outside Diameter (in)	15.68 in
Number of Flanges	3
Pitch Diameter (B)	15.7
Bushing Used	SK
Belt Type	Classic or 358
Datum Diameter (B)	15.4
Pitch Diameter (A)	15.2
Material	Cast Iron
Pulley Material	Cast Iron
Bore (Min) (in)	0.5 in
Belt Section	A, B
Product Type	Multiple Sheaves
Bore Type	QD Bushed
Face Width (in)	1.75
Bushing Bore Range	0.500 - 2.625

General Specifications

UPC	662289376865
Weight	25.93 LB
Packaged Length	15.90 IN
Packaged Width	15.80 IN
Packaged Height	2.10 IN
